Product Summary

The EP1C6F256C8N is a Cyclone FPGA. The device densities up to 20,060 logicelements (LEs) and up to 288 Kbits of RAM. With features like phaselocked loops (PLLs) for clocking and a dedicated double data rate (DDR) interface to meet DDR SDRAM and fast cycle RAM (FCRAM) memory requirements, Cyclone device is a cost-effective solution for data-path applications.

Parametrics

EP1C6F256C8N absolute maximum ratings: (1)VCCINT, Supply voltage: -0.5 V min and 2.4 V max With respect to ground; (2)VI, DC input voltage: -0.5 V min and 4.6 V max; (3)IOUT, DC output current, per pin: -25 mA min and 25 mA max; (4)TSTG, Storage temperature: -65 to 150℃; (5)TAMB, Ambient temperature: -65 to 135℃; (6)TJ, Junction temperature: 135℃ max at BGA packages under bias.

Features

EP1C6F256C8N features: (1)Up to 294,912 RAM bits (36,864 bytes); (2)Supports configuration through low-cost serial configuration device; (3)Support for LVTTL, LVCMOS, SSTL-2, and SSTL-3 I/O standards; (4)Support for 66-MHz, 32-bit PCI standard; (5)Low speed (311 Mbps) LVDS I/O support; (6)Up to two PLLs per device provide clock multiplication and phase shifting; (7)Up to eight global clock lines with six clock resources available per logic array block (LAB) row.

Diagrams

EP1C6F256C8N block diagram
