MX29LV400TTC-90

MX29LV400TTC-90, 4M-BIT CMOS SINGLE FLASH MEMORY, 4V, 200mA, Macronix International

Rated 5 Rating 5 | reviews | Write a review

Price:: US $1.00~1.30 / piece [Get Latest Price]

Reference price:

Qty (lots)	Price/lot
	US $1.00~1.30

PartNumber:: MX29LV400TTC-90

Brand:: Macronix International - MXIC | Pack: TSOP | D/C: 04+

Availability:: Supply Ability: 10000/Week Can Ship Immediately
Delivery: 10-15 Business Days (ships out within 3 Business days)

Quantity:: piece

Total Price:: US $0

Place Order via Escrow Service

Sold By

Ms. Lena's store

(China (Mainland))

add to my favourite

100% Positive feedback

Detailed seller ratings

Visit Store

Contact Now

Esrcow Service

Place orders confidently and securely via it

Safe payments
Quick and easy transactions
Free service charges

Learn More >>

Previous Next

Products Upload time: 2012-07-20

From Other Seller

Part Number:MX29LV400TTC-90
US $1.00 - 1.30
ECA1HHG4R7

US $10.00 - 10.00 / Piece
(0) Remove
ECA1HHG100

US $10.00 - 10.00 / Piece
(0) Remove
Quantity:

piece

Product Summary

The MX29LV400TTC-90 is a 4-mega bit Flash memory or-ganized as 512K bytes of 8 bits or 256K words of 16 bits. MXIC’s Flash memories offer the most cost-effec-tive and reliable read/write non-volatile random access memory. The MX29LV400TTC-90 is packaged in 44-pin SOP, 48-pin TSOP and 48-ball CSP. It is designed to be reprogrammed and erased in system or in standard EPROM programmers. The standard MX29LV400TTC-90 offers access time as fast as 55ns, allowing operation of high-speed microproces-sors without wait states.

Parametrics

MX29LV400TTC-90 absolute maximum ratings: (1)Storage Temperature Plastic Packages: -65℃ to +150℃; (2)Ambient Temperature with Power Applied: -65℃ to +125℃; (3)Voltage with Respect to Ground VCC: -0.5 V to +4.0 V; A9, OE, and RESET: -0.5 V to +12.5 V; All other pins: -0.5 V to VCC +0.5 V; (4)Output Short Circuit Current: 200 mA.

Features

MX29LV400TTC-90 features: (1)Extended single - supply voltage range 2.7V to 3.6V; (2)524,288 x 8/262,144 x 16 switchable; (3)Single power supply operation-3.0V only operation for read, erase and program operation; (4)Fast access time: 55R/70/90ns; (5)Low power consumption; (6)Command register architecture, Byte/word Programming (9us/11us typical); Sector Erase (Sector structure 16K-Byte x 1, 8K-Byte x 2, 32K-Byte x1, and 64K-Byte x7); (7)Auto Erase (chip & sector) and Auto Program; (8)Erase suspend/Erase Resume; (9)Status Reply; (10)Ready/Busy pin (RY/BY); (11)Sector protection; (12)100,000 minimum erase/program cycles; (13)Latch-up protected to 100mA from -1V to VCC+1V; (14)Boot Sector Architecture, T = Top Boot Sector; B = Bottom Boot Sector; (15)Low VCC write inhibit is equal to or less than 2.3V; (16)Package type: 44-pin SOP; 48-pin TSOP; 48-ball CSP; (17)Compatibility with JEDEC standard, Pinout and software compatible with single-power supply Flash.
