Product Summary

The PS7142L-1A-E3 is a 1-Channel Optical Coupled MOS FET. The PS7142L-1A-E3 is a solid state relay containing GaAs LEDs on the light emitting side (input side) and MOS FETs on the output side. The device is suitable for analog signal control because of its low offset and high linearity. The device has a surface mount type lead. The application of the PS7142L-1A-E3 include Exchange Equipment, Measurement Equipment, FA/OA Equipment.

Parametrics

PS7142L-1A-E3 absolute maximum ratings: (1)Forward Current (DC), IF: 50 mA; (2)Reverse Voltage, VR: 5.0 V; (3)Power Dissipation, PD: 50 mW; (4)Peak Forward Current, IFP: 1 A; (5)Break Down Voltage, VL: 400 V; (6)Continuous Load Current, Connection A, IL: 200 mA; Connection B: 250; Connection C: 400; (7)Pulse Load Current (AC/DC Connection), ILP: 400 mA; (8)Power Dissipation, PD: 560 mW; (9)Isolation Voltage, BV: 1500 Vr.m.s.; (10)Total Power Dissipation, PT: 610 mW; (11)Operating Ambient Temperature, TA: -40 to +85℃; (12)Storage Temperature, Tstg: -40 to +100℃.

Features

PS7142L-1A-E3 features: (1)1 Channel type: 1 a output; (2)Low led operating current: IF= 2mA; (3)Designed for ac/dc switching line changer; (4)Small package: 6-Pin DIP; (5)Low offset voltage; (6)PS7142L-1A: Surface mount type; (7)Safety standards: UL approved: File No. E72422 (S); BSIapproved: File No. 8245/8246; CSAapproved: File No. CA 101391.
