TPS5430QDDARQ1

TPS5430QDDARQ1, high-output-current PWM converter, SOP-8, 40V, 10mA, Texas Instruments

Rated 5 Rating 5 | reviews | Write a review

Price:: US $0.72~0.80 / piece [Get Latest Price]

Reference price:

Qty (lots)	Price/lot
	US $0.72~0.80

PartNumber:: TPS5430QDDARQ1

Brand:: Texas Instruments - TI | Pack: SOP | D/C: 12+

Availability:: Supply Ability: 10000/Week Can Ship Immediately
Delivery: 10-15 Business Days (ships out within 3 Business days)

Quantity:: piece

Total Price:: US $0

Place Order via Escrow Service

Sold By

Ms. Lena's store

(China (Mainland))

add to my favourite

100% Positive feedback

Detailed seller ratings

Visit Store

Contact Now

Esrcow Service

Place orders confidently and securely via it

Safe payments
Quick and easy transactions
Free service charges

Learn More >>

Previous Next

Products Upload time: 2012-05-21

From Other Seller

Part Number:TPS5430QDDARQ1
US $0.72 - 0.80
iphone5 data cable

US $4.00 - 5.00 / Piece
(0) Remove
LM64P101

US $240.00 - 300.00 / Piece
(0) Remove
Quantity:

piece

Product Summary

The TPS5430QDDARQ1 is a high-output-current PWM converter. The TPS5430QDDARQ1 integrates a low resistance high side n-channel MOSFET. Included on the substrate with the listed features are a high performance voltage error amplifier that provides tight voltage regulation accuracy under transient conditions; an undervoltage-lockout circuit to prevent start-up until the input voltage reaches 5.5 V; an internally set slow-start circuit to limit inrush currents; and a voltage feed-forward circuit to improve the transient response. The TPS5430DDAR device is available in a thermally enhanced, easy to use 8-pin SOIC PowerPAD package. The applications of the TPS5430QDDARQ1 include Consumer: Set-top Box, DVD, LCD Displays, Industrial and Car Audio Power Supplies, Battery Chargers, High Power LED Supply and 12V/24V Distributed Power Systems.

Parametrics

TPS5430QDDARQ1 absolute maximum ratings: (1)VI, Input voltage range: VIN: -0.3 to 40 v; BOOT: -0.3 to 50 v; PH (steady-state): -0.6 to 40 v; (2)ENA: -0.3 to 7 v; (3)BOOT-PH: 10v; (4)VSENSE: -0.3 to 3v; (5)PH (transient < 10 ns): -1.2v; (6)IO, Source ,PH: Internally Limited; (7)Ilkg, Leakage current, PH: 10 mA; (8)TJ, Operating virtual junction temperature range: -40 to 150 ℃; (9)Tstg, Storage temperature: -65 to 150 ℃.
