Product Summary

The EP2C5T144C8N is belongs to cyclone II device. The Cyclone II family offers device with the Fast-On feature, which offers a faster power-on-reset (POR) time. Devices that support the Fast-On feature are designated with an “A” in the device ordering code. For example, EP2C5A, EP2C8A, EP2C15A, and EP2C20A. The EP2C5T144C8N is only available in the automotive speed grade. The EP2C5T144C8N is only available with the Fast-On feature and is available in both commercial and industrial grades. The Cyclone II “A” devices are identical in feature set and functionality to the non-A devices except for support of the faster POR time.

Parametrics

Specification: (1)M4K embedded memory blocks; (2)Up to 1.1 Mbits of RAM available without reducing available logic; (3)4,096 memory bits per block (4,608 bits per block including 512 parity bits); (4)Variable port configurations of ×1, ×2, ×4, ×8, ×9, ×16, ×18, ×32, and ×36; (5)True dual-port (one read and one write, two reads, or two writes) operation for ×1, ×2, ×4, ×8, ×9, ×16, and ×18 modes; (6)Single-ended I/O standard support, including 2.5-V and 1.8-V, SSTL class I and II, 1.8-V and 1.5-V HSTL class I and II, 3.3-V PCI and PCI-X 1.0, 3.3-, 2.5-, 1.8-, and 1.5-V LVCMOS, and 3.3-, 2.5-,and 1.8-V LVTTL.

Features

Features: (1)High-density architecture with 4,608 to 68,416 LEs; (2)Embedded multipliers; (3)Advanced I/O support; (4)Flexible clock management circuitry; (5)Intellectual property.

Diagrams

Image Part No Mfg Description Data Sheet Download Pricing
(USD)
Quantity
EP2C5T144C8N
EP2C5T144C8N


IC CYCLONE II FPGA 5K 144-TQFP

Data Sheet

0-1: $7.68
