Product Summary
The TMS320F2808PZA is a Digital Signal Processor.
Parametrics
TMS320F2808PZA absolute maximum ratings: (1)Supply voltage range, VDDIO, VDD3VFL: -0.3 V to 4.6 V; (2)Supply voltage range, VDDA2, VDDAIO: -0.3 V to 4.6 V; (3)Supply voltage range, VDD: -0.3 V to 2.5 V; (4)Supply voltage range, VDD1A18 , V DD2A18: -0.3 V to 2.5 V; (5)Supply voltage range, VSSA2, VSSAIO, VSS1AGND, V SS2AGND: -0.3 V to 0.3 V; (6)Input voltage range, VIN: -0.3 V to 4.6 V; (7)Output voltage range, VO: -0.3 V to 4.6 V; (8)Input clamp current, I IK (V IN < 0 or V IN > V DDIO ): ±20 mA; (9)Output clamp current, I (V < 0 or V > V ): ±20 mA; (10)Junction temperature range: -40℃ to 150℃; (11)Storage temperature range: -65℃ to 150℃.
Features
TMS320F2808PZA features: (1)High-Performance Static CMOS Technology; (2)JTAG Boundary Scan Support; (3)Dynamic PLL Ratio Changes Supported; (4)On-Chip Oscillator; (5)Watchdog Timer Module; (6)Any GPIO A Pin Can Be Connected to One of the Three External Core Interrupts; (7)Peripheral Interrupt Expansion (PIE) Block; (8)That Supports All 43 Peripheral Interrupts; (9)128-Bit Security Key/Lock; (10)Three 32-Bit CPU Timers.
Diagrams
Image | Part No | Mfg | Description | Pricing (USD) |
Quantity | |||||||||||||
---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
TMS320F2808PZA |
Texas Instruments |
Digital Signal Processors & Controllers (DSP, DSC) 32-Bit Digital Sig Controller w/Flash |
Data Sheet |
|
|
|||||||||||||
